How to troubleshoot hot tub and spa equipment pack?

Using volt meter on a minimum 240 volt scale (120 on a 120 pack) check to see whether the power coming in is enough to power the pack: 210-240 on 240v, 110-120 on 120v. If not, have an electrician look into it. 5. On 240v observe contactor or heater relay.

Can a hot tub be wired under a power supply?

Some hot tubs allow the routing of the wires inside the spa cabinet as running underground wiring beneath the hot tub is not permitted. It is also not allowed to situate the hot tub directly under overhead power or communication wires. Turn on the power supply and the newly installed hot tub circuit breaker.

What to do if your hot tub has no voltage?

If the bulb is exposed to air, COVER IT. If out of the well, insert and center it. If no voltage is found, adjust calibration on the thermostat by turning Allen screw at top of switch clockwise until a “click” is heard or you reach 1/4 revolution (whichever comes first).

Do you need a circuit breaker for a hot tub?

Direct connection to a circuit breaker is the primary factor that distinguishes between a wired hot tub and a plug and play type of spa. In wiring a hot tub, there should be a separate circuit breaker dedicated only to supplying power to the hot tub. Install the appropriate size of a circuit breaker to the service panel solely for this purpose.

How to safely disconnect hot tub circuit wiring?

Precaution: Identify the circuit, turn it OFF and Tag it with a Note before working with the wiring. Notice: Installing additional electrical wiring should be done according to local and national electrical codes with a permit and be inspected. The following is the basic process of how an electrician removes Hot Tub Circuit Wiring.

Can you use a GFCI disconnect on a 240V hot tub?

Use a GFCI disconnect designed for 240V hot tubs, 4 or 3 wire spa types. The interactive schematic diagram below shows 3 and 4 wire configurations. Select the wiring configuration that your spa requires: Size the feeder circuit breaker in the service panel according to the spa’s load requirement.

What kind of wiring do you need for a 240V hot tub?

In our movie below, we’ve already poured a level cement slab and placed our hot tub on it. Per the owner’s manual, our hot tub requires a 240V, 50 amp 4-wire electrical hook-up, using AWG #6 copper wire. The electrician is running all buried wiring in 1″ rigid Sch-40 grey PVC electrical conduit.

Do you use the same troubleshooting techniques at the spa?

DISCLAIMER: We at the Spa Care Center use the same troubleshooting techniques that have been provided to you and are fully confident that they work. But, when dealing with water and electricity, it always provides a danger that must be respected.

What are the error codes on the spa side?

Flow Switch (heater is deactivated. Pump may also be deactivated). Panel sensors have been pressed too many times in a short period of time. Circuit Board temperature has exceeded acceptable limit. Freeze protection. No action is necessary. Freeze protection. No action is necessary. Communication between the panel and circuit board is faulty.

What to do if your spa pump wont turn on?

DO NOT continue to operate the pump this way or it will cause damage to the spa Turn the spa on and wait for PR (Priming Mode) to appear on the topside display. Press the JETS1 button to turn on the pump, then let it run for 10 seconds.

When does spa go into priming mode what does it mean?

Inadequate water detected in heater.. Inadequate water detected in heater. (Displays on third occurrence of “dr” message). Spa is shut down. When spa is first actuated, it will go into Priming Mode. Interlock failure – possible pump or ozone spike. Unknown water temperature. (Displays when first powered up after refill).

Where can I get spa parts from the spa Guy?

Spa Parts Unsurpassed In Quality Found Here! The Spa Guy offers Parts for most Spa Brands. If You have a need for a part first got to our website Hot Tub Parts of America and see if you can find the part..

Can you replace the model number on a spa pack?

If you have the old model number of the spa pack you are replacing, you could either order the same pack by model number, or choose a new pack that offers the same functions.

Do you need to replace a spa control system?

Instead of hauling your old spa off to the dump, consider installing an entirely new control system! Installation is simple for someone with average mechanical skills. You could save thousands of dollars over buying new parts for aging equipment. Let’s take a closer look at identifying and selecting a new spa control kit for your hot tub. CAUTION!

Can a hot tub circuit board be replaced?

Getting a replacement spa pack or circuit board for a hot tub involves being sure you order the correct configuration. If you have the old model number of the spa pack you are replacing, you could either order the same pack by model number, or choose a new pack that offers the same functions.

What to do when your spa panel is not working?

Contact your Dealer or Service Organization to check the Switch Numbers or Setting Values Displayed, and Correct as Necessary to Match the Equipment in the Spa System, or Continue for a Detailed Test Procedure. 1. Turn OFF the Power to the System and Turn it back ON again to put System into Priming Mode.

Why does my hot tub keep running at 108f?

If the display says 108F and the water is actually that temp. and the “heat on” symbol/light shut off on the display at the set temp. of 100F…. Then you have a circuit board that is continuing to power the heater after it supposed to shut off. That would mean a bad board.

What should I do if my Marquis Spa is not hot?

Check the LCD temperature display, if the Marquis spa is not sufficiently hot. Turn up the temperature, if it is below the desired temperature. Remove the filter cartridge and make sure it is clean. If it is dirty, replace it. Make sure the spa is not in Sleep Mode. Wait 12 to 24 hours for the water to heat up.

What to do if your hot tub cord is 240?

If 240 is found where the cord meets the relay but not at the element, check the “Hi Limit’ switch breaking power to one line on the element. To do this, look to see if the heater indicator light is on.

Why is my Spa 2 speed pump not working?

II have a 2002 Optima spa. Several months ago the button on the top-side control panel for the 2 speed pump (#1) stopped working. There’s a second, smaller control panel on the opposite side of the tub which also will not work. But when the preset filter cycles occur the pump will come on and the icon comes on on the display.

How to test a hot tub pump or spa pump for failure?

a) The spa pack receptacle into which the pump is plugged does not produce 230 or 120 volts ac, or c) 230 or 120 volts is available at the pump motor terminals and the motor rotates normally but the pump is not producing any flow. When tracing a pump problem you want to disconnect one terminal of the heater element.

How do I fill up my hot tub for the first time?

Do Timely Maintenance as directed, and most importantly, ENJOY YOUR SPA! As always, if you have any questions about filling up your hot tub for the first time, please don’t hesitate to ask. You can reach us by phone at (317) 912-1633, or you can contact your Royal Spa representative directly.

Can a 5HP jetting pump be installed on a 4hp hot tub?

If a larger jetting pump was installed, say a 5Hp when the original one was a 4HP this would overload the hot tubs control systems, a 5HP 240 volt motor draws about 4.4 amps more on high speed (See illustration below) then a 4HP. Also, it could overload the breaker and the wire to the hot tub creating a fire hazard.

What kind of pump do I need for my hottub?

S-Class, Heater model # SC-CF-P122-02-L3-H5.5-H, Pump – 14 FLA, Ozone 3A, Light 12 VAC1A, Heater 23A, Pump – Flomaster XP2, Model # – T55MWCBB-1185, Volts 230 Hope this helps okay, that’s an aquaflo flowmaster pump, should be two speed, if you hit the jets button, will the pump run on high speed, or still the same problem?

What causes a hot tub pump to fail?

If the pressure was increased it would overload the original design as well as cause the larger pump motor to work harder under stress trying to push a higher volume of water through plumbing then it was designed to and the motor could fail prematurely.

Can a 1.5hp water pump be installed?

The electrical installation would be the same as any 1-speed pump because the switch it built-in. The plumbing uses union fittings which are also easier to deal with. The filter will be fine with the 1.5HP, but that is just going to cost you more money upfront and more money on electricity to run.
